My laptop has really high resolution so everything is super small small and I couldn’t tell the difference between the 5 and 8 and the 8 stuck in my head and propagated. 6.35 vs 6.38 has more to do with my bad eyesight than anything else.

Not a great answer, but the truth: my bad. Why do you set the cutter diameter to 6.38 instead of 6.35 for a 1/4" bit? I started taking those out and it really speeds things up because the stock z axis is super slow, but only take them out if the location before and after the segment change is the same. between each segment, the generated gcode raises and lowers the z axis. Double check your numbers and try again.ĮDIT: One last point of frustration. If no gcode is generated, then there is a problem. When the working dialog closes, it is finished and you can close the path to gcode window and go upload the gcode file. It will take a while depending on how complicated the cut is and how many segments there are. If the preferences tab is selected, it will not generate gcode, so make sure the path to gcode tab is selected then click “apply”Ĭlick ok then you will see this if it is working:

Set up origin points with the same layer selectedĮxtensions->gcodetools->orientation pointsĭepth function is d, cutting order is path by path (cuts entire job at each depth), if you do path by path, it cuts each path segment layer by layer, so it will cut part of the H 4 times and then move to the next piece completing all of the cut layer then go back and do the tab layer. I’ve done as much as 5 mm, but there is a proportional speed drop that must accompany it to keep the bit cool so you don’t overheat (Based on what I’ve read and the quality of cuts that resulted when I tried - your mileage may vary - I’d love to have more info on what settings to use to be efficient and high quality).ī. Depth step is the depth your tool will cut in 1 pass in mm. Penetration angle is always 90 for maslow because the router on the sled is flat on the work surface. You can cut at 750, but it may not be good quality and your tool will dull faster if it gets hot. Set your feed rate based on your material in mm/min (between 300 and 800). change diameter to 6.35 if you are using a 1/4" bit or 3.175 if you are using a 1/8th inch bit. or just click on the text and then click on the text tool bar on the left or the right side of the page. If your attempts to edit add numbers over the top, then undo and retry. Do this by double clicking on them and then when you get the text curson you can edit them. If you paste it in and it isn’t lined up, you can move it and it will snap to the other layer.Īfter pasting, they may not line up, so move it if you need to. With both layers visible, you should not be able to tell them apart, but you can toggle which one you see hiding or viewing it in the layer viewer.

Create a copy of your drawing and select the other layer and paste it.

Don’t mess with the lock or you won’t be able to edit or select anything in that layer. If the eye is black this is viewable, if greyed, then it is hidden. In the layer viewer on the right, you can select which layer is visible by clicking on the eye. I’m not sure if it matters what order it is in, but it works this way.

Create a second layer, rename it “tabs.” Move it below the first layer as a matter of convention.

Move the letters together so they overlap, convert object to path, cut path, then ungroup and then union it so it removes the extra lines. This only matters because it helps you see the cuts that will overlap and where to put in tabs later. If text, change fill to none, set stroke paint to black and stroke style to 3 mm or 4 mm (3.175 mm if you want to be precise) for 1/8" bit or 6 mm or 7 mm (6.35 mm) for 1/4" bit. After some editing, I have my shape as an outline only with the thickness of the line the same size as my cutting bit so I can see what it will look like.
